Today, let’s take a look at interesting facts about Gadolinium and answer the following questions: “Why Is Gadolinium Considered A Rare Earth Element?”, and “Why Is Gadolinium Considered A Critical Raw Material?”

Why Is Gadolinium Considered A Rare Earth Element?

Gadolinium is considered a rare earth element because it is one of the 15 lanthanide elements that form the core of the rare earth element group. With atomic number 64, gadolinium occupies a pivotal position in the lanthanide series between europium (63) and terbium (65), within the sequence that extends from lanthanum (atomic number 57) through lutetium (atomic number 71). As a lanthanide, gadolinium exhibits all the characteristic chemical properties that define this group, including the typical trivalent oxidation state (Gd3+) and an ionic radius that follows the systematic “lanthanide contraction” pattern. Traditionally, gadolinium marks the end of the light rare earth elements, as “the light REEs are lanthanum through gadolinium (atomic numbers 57 through 64),” though some authorities place it with the heavy rare earth elements.

Gadolinium’s unique position at the boundary between light and heavy rare earth elements reflects its transitional properties within the lanthanide series. With a crustal abundance of 6.2 parts per million, gadolinium is more abundant than the heavy rare earth elements that follow it but less abundant than most of the light rare earth elements that precede it. This abundance is comparable to elements like samarium (7.05 ppm) and significantly higher than the heavy rare earth elements like terbium (1.2 ppm) or dysprosium (5.2 ppm). Despite being more abundant than silver, gold, or platinum, gadolinium rarely concentrates into economically viable deposits, following the pattern common to all rare earth elements.

Gadolinium’s geochemical behavior exemplifies the fundamental characteristics of rare earth elements. Like all REEs, gadolinium has a high charge (+3) and an ionic radius that prevents its ready incorporation into common rock-forming minerals. This incompatibility causes gadolinium to concentrate with other rare earth elements during magmatic processes until specialized REE minerals crystallize. Gadolinium invariably occurs with other rare earth elements in nature, found in the primary REE minerals including bastnäsite ((REE)CO3F), monazite ((REE,Th)PO4), and xenotime. The principle that “REEs can substitute for one another in crystal structures, and multiple REEs typically occur within a single mineral” applies directly to gadolinium, which occupies crystal lattice positions interchangeably with neighboring lanthanides.

From scientific and industrial perspectives, gadolinium demonstrates unique properties while remaining firmly within the rare earth element family. Gadolinium is particularly notable as one of “six REE ions Gd3+ through Tm3+” that “have unusually large magnetic moments, owing to their several unpaired electrons.” In fact, gadolinium has seven unpaired electrons – the maximum possible for a lanthanide – giving it exceptional magnetic properties. This is exemplified by the development of Gd5(Si2Ge2), an alloy with a “giant magnetocaloric effect” near room temperature that “will allow magnetic refrigeration to become competitive with conventional gas-compression refrigeration.” Industrial applications of gadolinium leverage its rare earth properties: it serves in shielding for nuclear reactors, X-ray and magnetic resonance imaging scanning systems, where its unique combination of magnetic properties and neutron absorption makes it irreplaceable.

The combination of gadolinium’s position in the lanthanide series, its characteristic REE chemistry including the Gd3+ oxidation state, its transitional position between light and heavy REEs, its exceptional magnetic properties derived from its electronic configuration, and its consistent co-occurrence with other REEs in natural deposits unequivocally establishes gadolinium as a rare earth element.

Why Is Gadolinium Considered A Critical Raw Material?

Gadolinium is considered a critical raw material due to its irreplaceable role in medical imaging, emerging clean energy technologies, and defense applications, combined with severe supply chain vulnerabilities. Gadolinium is uniquely essential for magnetic resonance imaging (MRI) contrast agents, where “gadolinium phosphors are used in X-ray imaging and various medical applications, such as magnetic resonance imaging.” Its seven unpaired electrons – the maximum possible for a lanthanide – give gadolinium exceptional paramagnetic properties that make it irreplaceable for enhancing MRI image contrast. Additionally, gadolinium serves critical functions in nuclear reactor shielding, leveraging its high neutron absorption cross-section. Perhaps most significantly for future technology, the newly developed alloy Gd5(Si2Ge2) with a “giant magnetocaloric effect” near room temperature “will allow magnetic refrigeration to become competitive with conventional gas-compression refrigeration,” positioning gadolinium at the center of revolutionary energy-efficient cooling technology.

The criticality of gadolinium is amplified by the extreme concentration of global rare earth supply in China. Between 2011 and 2017, China produced approximately 84% of the world’s rare earth elements, while the United States contributed only about 4% during its limited production from 2012-2015. With a crustal abundance of 6.2 parts per million, gadolinium sits at the boundary between light and heavy rare earth elements, making it less abundant than the dominant light REEs but more accessible than the heavy REEs. At Mountain Pass, California, gadolinium represents a small fraction of the ore that is dominated by the first four light REEs, which “constitute 80 to 99% of the total.” When China announced export restrictions in 2010 through quotas, licenses, and taxes, it created vulnerability for gadolinium supply, particularly given that “nearly all REE separation and refining” occurs within China.

The strategic importance of gadolinium extends across medical, clean energy, and defense sectors with transformative potential. The magnetic refrigeration technology enabled by gadolinium alloys “could be employed in refrigerators, freezers, and residential, commercial, and automotive air conditioners,” offering “considerably more efficient than gas-compression refrigeration” without requiring “refrigerants that are flammable or toxic, deplete the Earth’s ozone layer, or contribute to global warming.” This positions gadolinium as central to achieving climate goals and energy efficiency targets. As one of “six REE ions Gd3+ through Tm3+” with “unusually large magnetic moments,” gadolinium is also essential for specialized permanent magnets used in defense applications and clean energy technologies. The fiscal year 2024 National Defense Stockpile plan includes potential acquisitions of gadolinium, reflecting official recognition of its strategic importance.

The combination of multiple critical factors establishes gadolinium as a vital raw material with significant supply risks. Expert panels from the National Research Council, U.S. Department of Energy, and European Commission have consistently ranked rare earth elements as having the highest “criticality” factor. For gadolinium, this criticality is particularly acute because its applications span from current medical necessities (MRI contrast agents) to transformative future technologies (magnetic refrigeration). The potential for magnetic refrigeration to revolutionize cooling systems globally – from home appliances to automotive air conditioning – while dramatically reducing energy consumption and eliminating harmful refrigerants, places gadolinium at the center of clean technology innovation.

With processing capabilities concentrated in China, no viable substitutes for its unique magnetic properties, and growing demand from medical, defense, and emerging clean energy applications, gadolinium represents a critical vulnerability where supply disruptions could impact both current medical capabilities and the development of next-generation energy-efficient technologies. The convergence of gadolinium’s irreplaceable role in medical imaging, its transformative potential in magnetic refrigeration, and the concentration of supply and processing in China firmly establishes gadolinium as a critical raw material for advanced economies.

Interesting Facts About Gadolinium

1. Gadolinium has the highest thermal neutron capture cross-section of any stable element, making it exceptionally effective at absorbing neutrons in nuclear reactor control rods and neutron shielding applications.
2. It exhibits the strongest magnetocaloric effect of any material near room temperature, meaning it heats up when entering a magnetic field and cools when leaving it – a property being explored for magnetic refrigeration technology.
3. Unique among rare earth elements, gadolinium becomes ferromagnetic below 20°C (68°F), while most other rare earths only show ferromagnetism at much lower temperatures near absolute zero.
4. Gadolinium possesses seven unpaired electrons in its 4f orbital – the maximum possible – giving it the highest magnetic moment of any element at 7.94 Bohr magnetons.
5. It’s the only lanthanide that crystallizes in a hexagonal close-packed structure at room temperature, while others typically form more complex crystal structures.
6. Gadolinium demonstrates an unusual resistivity behavior where electrical resistance actually increases as it transitions from paramagnetic to ferromagnetic state, opposite to most magnetic materials.
7. The element has two distinct magnetic phase transitions: ferromagnetic below 20°C and a spin reorientation at -185°C where magnetic moments change direction.
8. Gadolinium-157 isotope has a thermal neutron capture cross-section of 254,000 barns – about 66,000 times higher than hydrogen and among the highest known.
9. It’s the first element in the lanthanide series to fill exactly half of its 4f electron shell, creating exceptional magnetic stability and unique quantum mechanical properties.
10. Gadolinium compounds are used as MRI contrast agents because Gd³⁺ ions have seven unpaired electrons that create strong paramagnetic relaxation enhancement of water protons.
11. The element exhibits giant magnetostriction, changing shape by up to 60 parts per million in magnetic fields – useful for precision actuators and sensors.
12. Gadolinium has an anomalously high melting point (1313°C) compared to neighboring lanthanides, attributed to its half-filled 4f shell electronic configuration.
13. It’s one of only four elements (with dysprosium, holmium, and erbium) that exhibit significant magnetostrictive properties at room temperature.
14. Gadolinium metal unusually expands when alloyed with iron, while most rare earth-iron alloys contract – a property exploited in specialized alloys.
15. The element shows the Faraday effect more strongly than any other element, rotating the polarization plane of light in magnetic fields.
16. Gadolinium oxide has one of the highest dielectric constants (κ ≈ 20) among rare earth oxides, making it valuable for microelectronics applications.
17. It exhibits an unusual “colossal magnetoresistance” in certain compounds where electrical resistance can change by factors of thousands in magnetic fields.
18. Gadolinium is the only lanthanide that reacts slowly with cold water but rapidly with hot water, while others either react vigorously with cold water or not at all.
19. The element has the widest liquid range of any lanthanide (1313°C to 3273°C), spanning nearly 2000 degrees between melting and boiling points.
20. Gadolinium demonstrates quantum critical behavior near its Curie temperature, where quantum fluctuations compete with thermal fluctuations, making it a model system for studying quantum phase transitions.
